Er is geen uitgebreide omschrijving beschikbaar voor dit artikel.
Vendorcode WAB-8021
EAN code 4015867231630
Warranty 2 Jaar, Carry-In Qwerty
Gross size 230 x 38 x 107 mm
Gross weight 1.30
Packaging 1/ retail box
Packaging bulk
carton box
Color Wit
Certification
Compliance Certifications
CE, RoHS
Sustainability Certifications
CE, RoHS
Compatibility
Category
PoE Wireless Access Point Wireless LAN
Memory
Memory size (Internal)
512 MB
Displays
LED indicators
Power, Status, System
Network products
Ethernet LAN RJ-45 port(s) quantity
1
Ethernet LAN data rates
10, 100, 1000 MBps
Maximum data transfer rate
3000 MBps
Maximum data transfer rate (2.4 GHz)
574 MBps
Maximum data transfer rate (5 GHz)
2401 MBps
Power over Ethernet (PoE) support
Yes
WAN connection
Wireless LAN
Network features
Networking standards
IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3 u
Network products
Cabling technology
10/ 100/ 1000Base-T(X)
Channels quantity
165 channels
Maximum outdoor range
100 m
Number of products included
1 pc(s)
Power supply
Power consumption (typical)
16 W
Security
International Protection (IP) code
IP67
Security algorithms
WPA2, WPA3
Wireless network
Antenna direction type
Omni-directional
Number of SSID supported
8
Receiver sensitivity
2.4 GHz Radio : l 802.11b / 1 MBps / RX Sensitivity : -90
(dBm) l 802.11b / 11 MBps / RX Sensitivity : -85 (dBm) l
802.11g / 6 MBps / RX Sensitivity : -90 (dBm) l 802.11g /
54 MBps / RX Sensitivity : -72 (dBm) l 802.11n HT20 /
MCS0 / RX Sensitivity : -87 (dBm) l 802.11n HT20 / MCS7
/ RX Sensitivity : -70 (dBm) l 802.11n HT40 / MCS0 / RX
Sensitivity : -85 (dBm) l 802.11n HT40 / MCS7 / RX
Sensitivity : -68 (dBm) l 802.11ax HE20 / MCS0 / RX
Sensitivity : -83 (dBm) l 802.11ax HE20 / MCS11 / RX
Sensitivity : -60 (dBm) l 802.11ax HE40 / MCS0 / RX
Sensitivity : -83 (dBm) l 802.11ax HE40 / MCS11 / RX
Sensitivity : -56 (dBm) 5 GHz Radio : l 802.11 A HT20 /
6 MBps/ RX Sensitivity : -92 (dBm) l 802.11 A HT20 /
54 MBps/ RX Sensitivity : -72 (dBm) l 802.11n HT20 /
MCS0 / RX Sensitivity : -90 (dBm) l 802.11n HT20 / MCS7
/ RX Sensitivity : -70 (dBm) l 802.11n HT40 / MCS0 / RX
Sensitivity : -88 (dBm) l 802.11n HT40 / MCS7 / RX
Sensitivity : -68 (dBm) l 802.11ac VHT20 / MCS0 / RX
Sensitivity : -88 (dBm) l 802.11ac VHT20 / MCS8 / RX
Sensitivity : -70 (dBm) l 802.11ac VHT40 / MCS0 / RX
Sensitivity : -88 (dBm) l 802.11ac VHT40 / MCS7 / RX
Sensitivity : -68 (dBm) l 802.11ac VHT80 / MCS0 / RX
Sensitivity : -85 (dBm) l 802.11ac VHT80 / MCS9 / RX
Sensitivity : -58 (dBm) l 802.11ax HE20 / MCS0 / RX
Sensitivity : -88 (dBm) l 802.11ax HE20 / MCS11 / RX
Sensitivity : -62 (dBm) l 802.11ax HE40 / MCS0 / RX
Sensitivity : -86 (dBm) l 802.11ax HE40 / MCS11 / RX
Sensitivity : -58 (dBm) l 802.11ax HE80 / MCS0 / RX
Sensitivity : -84 (dBm) l 802.11ax HE80 / MCS11 / RX
Sensitivity : -55 (dBm l 802.11ax HE160 / MCS0 / RX
Sensitivity : -82 (dBm l 802.11ax HE160 / MCS11 / RX
Sensitivity : -51 (dBm)
Wireless LAN standard
IEEE 802.11 A/b/g/n/ac/ax
