WINDFORCE COOLING SYSTEM
The WINDFORCE cooling system features two 90mm unique blade fans, alternate spinning, 3 composite copper heat pipes directly touch the GPU, 3D active fans and Screen cooling, which together provide high efficiency heat dissipation.
ALTERNATE SPINNING
Reduce the turbulence of adjacent fans and increase airflow pressure..
3D ACTIVE FAN
The 3D Active Fan provides semi-passive cooling, and the fans will remain off when the GPU is in a low load or low power game.
UNIQUE BLADE FAN
The airflow is spilt by the triangular fan edge, and guided smoothly through the 3D stripe curve on the fan surface.
GRAPHENE NANO LUBRICANT
Graphene nano lubricant can extend the life of sleeve bearing fan by 2.1 times, close to the life of double ball bearing, and is quieter.
SCREEN COOLING
Extended heatsink allows air to pass through, providing better heat dissipation.
HEAT PIPES DIRECT TOUCH
The shape of the pure copper heat pipe maximizes the direct contact area with the GPU. The heat pipe also covers the VRAM through a metal plate contact to ensure proper cooling.
PROTECTION METAL BACK PLATE
The metal back plate not only provides an aesthetical shape, but also enhances the structure of the graphics card to provide complete protection.
Power Through The Game
GIGABYTE offers the best power supply solutions for your graphics cards. You can choose either the AORUS series or the UD series to power your graphics card.
GIGABYTE CONTROL CENTER
GIGABYTE CONTROL CENTER (GCC) is a unified software for all GIGABYTE supported products. It provides an intuitive interface that allows users to adjust clock speed, voltage, fan mode and power target in real-time.
Vendorcode GV-N406TWF2OC-16GD
EAN code 4719331314712
Warranty 2 jaar / 2 Years, Carry-In Qwerty
Gross size 120 x 41 x 201mm
Packaging 1/ retail box
Packaging bulk
carton box
Color Zwart
Coolers
Cooling technology
GIGABYTE WINDFORCE 2 X
Number of fans installed
2 fan(s)
Compatibility
Form factor
Half-Height Half-Length (HH/HL)
Memory
Graphics card memory type
GDDR6
Graphic cards
Discrete graphics card memory
16 GB
Graphics adapter model
GeForce RTX 4060 Ti
Graphics adapter-family
NVIDIA
Processor clock-frequency
2535 MHz
Processor turbo clock-frequency
2565 MHz
Displays
Maximum resolution
7680x4320 pixels
Number of displays supported
4
Power supply
Minimum system power supply
500 W
Supplementary power connectors
1x8-pin
Processor features
DirectX version
12 Ultimate
Storage
Data transfer rate
18 GBps
