Intel® Gaussian & Neural Accelerator
Intel® Gaussian & Neural Accelerator (GNA) is an ultra-low power accelerator block designed to run audio and speed-centric AI workloads. Intel® GNA is designed to run audio based neural networks at ultra-low power, while simultaneously relieving the CPU of this workload.
Intel® Deep Learning Boost (Intel® DL Boost)
A new set of embedded processor technologies designed to accelerate AI deep learning use cases. It extends Intel AVX-512 with a new Vector Neural Network Instruction (VNNI) that significantly increases deep learning inference performance over previous generations.
Intel® Speed Shift Technology
Intel® Speed Shift Technology uses hardware-controlled P-states to deliver dramatically quicker responsiveness with single-threaded, transient (short duration) workloads, such as web browsing, by allowing the processor to more quickly select its best operating frequency and voltage for optimal performance and power efficiency.
Intel® Turbo Boost Technology
Intel® Turbo Boost Technology dynamically increases the processor's frequency as needed by taking advantage of thermal and power headroom to give you a burst of speed when you need it, and increased energy efficiency when you don’t.
Idle States
Idle States (C-states) are used to save power when the processor is idle. C0 is the operational state, meaning that the CPU is doing useful work. C1 is the first idle state, C2 the second, and so on, where more power saving actions are taken for numerically higher C-states.
Vendorcode BX8071513500
EAN code 5032037260251
Warranty 3 Jaar / 3 Years, Pick-Up & Return
Packaging 1/ retail box
Packaging bulk
5/ carton box
Chipset
Direct Media Interface (DMI) Revision
4.0
PCIe configurations
1x16 + 1x4, 2x8 + 1x4
Memory
Maximum memory size
128 GB
Memory bandwidth (max)
76.8 GB/s
Memory types supported by processor
DDR4, DDR5
Graphic cards
Discrete graphics adapter
No
Discrete graphics card model
No
On-board graphics card DirectX version
12.0
On-board graphics card OpenGL version
4.5
On-board graphics card base frequency
300 MHz
On-board graphics card dynamic frequency (max)
1550 MHz
On-board graphics card model
Intel HD Graphics 770
On-board graphics card outputs supported
Embedded DisplayPort (eDP) 1.4b, DisplayPort 1.4 A, HDMI 2.1
Processor turbo clock-frequency
4.8 GHz
Displays
Performance-core base frequency
2.5 GHz
Performance-core boost frequency
4.8 GHz
Processors
Commodity Classification Automated Tracking System (CCATS)
740.17B1
Processors
Processor codename
Raptor Lake
Processor family
Intel® Core i5
Processor model
Intel® Core i5 13500
Processor number of cores
14
Processor number of threads
20
Power supply
Efficient-core base frequency
1.8 GHz
Efficient-core boost frequency
3.5 GHz
Processor features
Embedded options available
Yes
Enhanced Intel SpeedStep® Technology
Yes
Instruction set(s) supported
AVX 2.0, SSE4.1, SSE4.2
Intel Turbo Boost Max Technology 3.0
No
Intel Virtualization Technology (VT-x)
Yes
Intel Virtualization Technology for Directed I/O (VT-d)
Yes
Intel® AES New Instructions (Intel® AES-NI)
Yes
Intel® Hyper Threading Technology (Intel® HT Technology)
Yes
Intel® Thread Director
Yes
Intel® Turbo Boost Technology
2.0
