GIGABYTE CUSTOM-DESIGNED COOLING SYSTEM
GIGABYTE Custom-designed cooling system delivers an effective heat dissipation capacity for higher performance at lower temperatures.
LOW PROFILE DESIGN
Low profile design with 167mm card length saves more spaces and fits slim or smaller system.
FLEXIBLE CONNECTIVITY
Equip with one Dual-link DVI-D, one DP, and two HDMI ports and support up to 4 displays.
BUILT STRONG
ULTRA COOLING
Lower RDS(on) MOSFETs are specially designed to produce lower switching resistance for faster electric current charging and discharging at extremely low temperature.
LOW POWER LOSS
Metal Choke hold energy much longer than common iron-core chokes at high frequency, thus effectively reduce core energy loss and EMI interference.
LONGER LIFE
Lower ESR Solid Capacitors ensure better electronic conductivity for excellent system performance and longer lifespan.
FRIENDLY PCB DESIGN
Fully automated production process ensures top quality of the circuit boards and eliminates sharp protrusions of the solder connectors seen on the conventional PCB surface. This friendly design prevents your hands from getting cut or inadvertently damaging components when making your build.
IN TOTAL COMMAND
The interface and functionality of the software is subject to each model.
AORUS ENGINE
The cutting edge intuitive interface allows you to adjust the clock speed, voltage, fan performance and power target in real-time according to your game’s requirements.
Vendorcode GV-N1630OC-4GL
EAN code 4719331311131
Warranty 3 jaar, Carry-In Qwerty
Gross size 295 x 210.5 x 50 mm
Packaging 1/ retail box
Packaging bulk
carton box
Color Zwart
Coolers
Number of fans installed
2 fan(s)
Connectivity
Interface type
PCI Express x16 3.0
Compatibility
Form factor
ATX (low-profile)
Windows operating systems supported
Windows 10x64, Windows 11x64
Memory
Graphics adapter Memory type
GDDR6
Graphics adapter memory bus
64-bit
Graphics adapter memory size
4 GB
Graphics card memory type
GDDR6
Memory bandwidth (max)
96 GB/s
Memory clock-frequency
12000 MHz
Graphic cards
Discrete graphics card memory
4 GB
Graphics adapter model
GeForce GTX 1630
Graphics adapter-family
NVIDIA
Multi-GPU (SLI/CrossfireX) support
Not supported
Processor clock-frequency
1800 MHz
Displays
Maximum resolution
7680x4320 pixels
Number of displays supported
4
Power supply
Minimum system power supply
300 W
Properties
Bracket height
Low-Profile (LP)
