GIGABYTE CUSTOM-DESIGNED COOLING SYSTEM
GIGABYTE Custom-designed cooling system features a 80mm unique blade fan, delivering an effective heat dissipation capacity for higher performance at lower temperatures.
COMPACT SIZE FOR EASY INSTALLATION
With less than 170mm in length, the graphics card can be easily installed in any small chassis.
UNIQUE BLADE FAN
The airflow is spilt by the triangular fan edge, and guided smoothly through the 3D stripe curve on the fan surface, effectively enhancing the airflow.
ULTRA COOLING
Lower RDS(on) MOSFETs are specially designed to produce lower switching resistance for faster electric current charging and discharging at extremely low temperature.
LOW POWER LOSS
Metal Choke hold energy much longer than common iron-core chokes at high frequency, thus effectively reduce core energy loss and EMI interference.
LONGER LIFE
Lower ESR Solid Capacitors ensure better electronic conductivity for excellent system performance and longer lifespan.
FRIENDLY PCB DESIGN
Fully automated production process ensures top quality of the circuit boards and eliminates sharp protrusions of the solder connectors seen on the conventional PCB surface. This friendly design prevents your hands from getting cut or inadvertently damaging components when making your build.
AORUS ENGINE
The cutting edge intuitive interface allows you to adjust the clock speed, voltage, fan performance and power target in real-time according to your game’s requirements.
Vendorcode GV-N1656D6-4GD
EAN code 4719331310448
Warranty 2 jaar / 2 Years, Carry-In Qwerty
Gross size 152 x 36 x 114mm
Packaging 1/ retail box
Packaging bulk
carton box
Color Zwart
Coolers
Fan diameter(s) support
8 cm
Number of fans installed
1 fan(s)
Connectivity
Interface type
PCI Express x16 3.0
Memory
Graphics card memory type
GDDR6
Memory clock-frequency
12000 MHz
Graphic cards
Discrete graphics card memory
4 GB
Graphics adapter model
GeForce GTX 1650
Graphics adapter-family
NVIDIA
Multi-GPU (SLI/CrossfireX) support
Not supported
Processor clock-frequency
1590 MHz
Displays
Maximum resolution
7680x4320 pixels
Power supply
Minimum system power supply
300 W
Properties
Bracket height
Low-Profile (LP)
Storage
Data transfer rate
192 GBps
