SUPERCHARGED PERFORMANCE
The Radeon™ RX 6000 Series graphics cards can take on the most demanding titles at maximum settings with all the latest features enabled. With up to 80 powerful graphics compute units, coupled with up to 16GB of high-speed GDDR6 memory, and up to 128MB of low-latency AMD Infinity Cache™, these cards redefine enthusiast level performance.
VIVID VISUALS
Experience a new level of immersion with the Radeon™ RX 6000 Series graphics cards with support for the latest software innovations such as DirectX® 12 Ultimate and the latest AMD FidelityFX™ technology feature set, enabling realistic lighting, shadows, and reflections in extreme detail. AMD FidelityFX™ technology features are optimized for the AMD RDNA™ 2 architecture to power the next generation of gaming visuals at high framerates, providing a mesmerizing gaming experience.
ELEVATED EXPERIENCES
The new Radeon™ RX 6000 Series graphic cards are optimized for DirectStorage to help reduce load times in games and bring expansive worlds to life in amazing detail. Complete the experience with the widest available display ecosystem on the market, supporting the latest HDMI™ 2.1 VRR technology with the 2000+ AMD FreeSync technology-enabled gaming displays available at high refresh rates. With the new AMD Link™ 5.0, enjoy co-op with up to 4 players and experience your games across different devices seamlessly, as easy as clicking a button.
GET A BOOST IN FRAMES FOR YOUR GAMES
Maximize image quality and supercharge performance with AMD FidelityFX™ Super Resolution (FSR) across select supported games or boost your frame rates across a wide number of games with Radeon™ Super Resolution (RSR) to deliver high-quality, high-resolution, and high framerate gaming experiences on AMD Radeon™ graphics cards.
THE BEST GAMING EXPERIENCE FOR THE BEST GAMING OS
Windows® 11 is created for the ultimate PC gaming, featuring superior graphics, amazing speed, and an incredible selection of games. Windows 11 includes gaming features like DirectX® 12 Ultimate, DirectStorage, and Auto HDR. AMD processors, graphics, and software all stand ready to supercharge your gaming experience with the new operating system from day one.
WINDFORCE 3X COOLING SYSTEM
The WINDFORCE 3X cooling system features three 80mm unique blade fans, alternate spinning, 5 composite copper heat pipes directly touch the GPU, 3D active fan and Screen cooling, which together provide high efficiency heat dissipation.
ALTERNATE SPINNING
Alternate Spinning can reduce the turbulence of adjacent fans and increase air pressure.
SMOOTH AIRFLOW
GIGABYTE turns the adjacent fans in the opposite direction, so that the airflow direction between the two fans is the same, reducing the turbulence and enhancing the airflow pressure.
3D ACTIVE FAN
The 3D Active Fan provides semi-passive cooling, and the fans will remain off when the GPU is in a low load or low power game.
UNIQUE BLADE FAN
The airflow is spilt by the triangular fan edge, and guided smoothly through the 3D stripe curve on the fan surface.
GRAPHENE NANO LUBRICANT
Graphene nano lubricant can extend the life of sleeve bearing fan by 2.1 times, close to the life of double ball bearing, and is quieter.
SCREEN COOLING
Extended heatsink design allows air flow to pass through, providing better heat dissipation.
HEAT PIPES DIRECT TOUCH
The shape of the pure copper heat pipe maximizes the direct contact area with the GPU.
RGB FUSION 2.0
With 16.7M customizable color options and numerous lighting effects, you can choose lighting effects or synchronize with other AORUS devices.
PROTECTION METAL BACK PLATE
The metal back plate not only provides an aesthetical shape, but also enhances the structure of the graphics card to provide complete protection.
POWER INDICATOR
When experiencing any power supply abnormality, the indicator will alert gamers by flashing light.
EXTREME DURABILITY AND OVERCLOCKING
The graphics card uses the better power phase design to allow the MOSFET to operate at lower temperature, and over-temperature protection design and load balancing for each MOSFET, plus the Ultra Durable certified chokes and capacitors, to provide excellent performance and longer system life.
FRIENDLY PCB DESIGN
Fully automated production process ensures top quality of the circuit boards and eliminates sharp protrusions of the solder connectors seen on the conventional PCB surface. This friendly design prevents your hands from getting cut or inadvertently damaging components when making your build.
AORUS ENGINE
The cutting edge intuitive interface allows you to adjust the clock speed, voltage, fan performance and power target in real-time according to your game’s requirements.
Vendorcode GV-R675XTGAMING OC-12GD
EAN code 4719331310820
Warranty 2 jaar / 2 Years, Carry-In Qwerty
Gross size 115 x 49 x 281mm
Gross weight 0.00
Packaging 1/ retail box
Packaging bulk
carton box
Color Zwart, zilver
Coolers
Cooling technology
GIGABYTE WINDFORCE 3 X
Fan diameter(s) support
8 cm
Number of fans installed
3 fan(s)
Compatibility
Form factor
Full-Height Full-Length (FH/FL)
Memory
Graphics card memory type
GDDR6
Memory bandwidth (max)
432 GB/s
Memory clock-frequency
18000 MHz
Graphic cards
Discrete graphics card memory
12 GB
Graphics adapter model
AMD Radeon™ RX 6750 XT
Graphics adapter-family
AMD
Multi-GPU (SLI/CrossfireX) support
Not supported
Processor turbo clock-frequency
2533 MHz
Displays
Maximum resolution
7680x4320 pixels
Number of displays supported
4
Power supply
Minimum system power supply
650 W
Supplementary power connectors
1x6-pin, 1x8-pin
Processor features
DirectX version
1‎2 Ultimate
Properties
Bracket height
Full-Height (FH)
Product colour
Black, Silver
